Product Description

This breakout board has been designed as an accessory for our very popular ILDA Gem Pocket laser projector tester.
The breakout provides easy connections for all the signals from the ILDA GEM, scanner X/Y Shutter and colour outputs RGB. The signals are available on a set of screw terminals AND Molex K style connectors, and is made on an extra thick 2mm pcb substrate for robustness. The board has a 25 way Male D connector that will allow it to be fitted directly to the ILDA GEM Pocket without the use of a lead, and it allows you to use the ILDA Gem Pocket for testing and adjusting parts not installed in a projector or during assembly.
This product can also be used as a simple breakout for wiring to the laser projector.

For full details of the ILDA GEM Pocket see



Customer Reviews

ILDA Gem Breakout

Item in Stock (4 Available)
